CBX510 CONNECTION BOX
PRODUCT REFERENCE GUIDE 53
• CBX510 - used for typical standalone or master cameras (cannot be used for slave
cameras). It provides general access to digital input/output signals. It doesn't
require special jumpers to set operation or power sourcing.
• CBX800 - used for Fieldbus communication between standalone or master cam-
eras and a Host. Various Fieldbus modules can be i
nstalled in the CBX800. The
master camera communicates through its main serial interface to the CBX800
which must be programmed for the specific Fieldbus communication to the Host.
It also provides general access to digital input/output signals.The table below indi-
cates the available options for each recommended CBX Connection Box.
OPTIONS
DEVICE Tach Input
Trigger
Input
Gen
eral
Purpose
Input
General
Purpose
Output 1
General
Purpose
Output 2
Works as
Slave
Works as
Master
CBX100 X X X X X *
w/ jumper 
(Ref to ID+)
CBX510 X X X X X X
CBX800 X X X X X X
w/ jumper
(Ref to ID+)
* When working with a slave the jumper is not installed.
CBX510 CONNECTION BOX
Complete installation information for the connection box is available in the CBX510
Installation Manual available at www.datalogic.com. The interior of the box is shown
below.
Although multiple AV500/AV900 cameras can have a CBX box,
only one of the CBX boxes in
the system can have the Jumper to make it the Master.
