AV500 TIMING AND DISTANCE DIAGRAMS
PRODUCT REFERENCE GUIDE
357
Focusing with a Light Curtain and S85
Identifier
Item 1
Item 2
Distance
Standar
d (in.)
Metric
A
T
rigger Source
S85 #1
5
127
B
S85 #1
S85 #2
5
127
C
S85 #2
Light Curtain
No distance requir
ed
D
Light Curtain
AV
50
0
12
305
Position Sensor Delay
127
