X-PRESS FUNCTIONALITY
PRODUCT REFERENCE GUIDE 15
Focus/Locate
This function causes the camera to automatically learn the fixed focus distance and sen-
sitivity. The Focus LED blinks to indicate this sta
te. To exit the Focus/Locate Mode, press
the X-PRESS button once.
The focus procedure is as follows:
1. Place a package with barcode at the desired fixed focus distance in the center of
the c
amera’s
view.
2. Enter the focus function. The Focus LED will blink.
3. Wait until the Focus LED is steady. This indic
ate
s the camera has determined the
fixed focus distance and sensitivity.
4. To commit the settings and exit, press the XPress button once.
5. This procedure ends when the values are com
mitted or after a timeout of 60 sec-
onds. If it times out the data is not saved.
Setup
Once entered, the camera aiming laser is enabled. The SETUP LED blinks to indicate the
aiming laser is enabled. Use the aiming laser to aim the camera properly during mount-
ing.
To exit Setup Mode, press the X-PRESS push button once.
Setup Mode will timeout after about 5 minutes.
AutoLearn
Once entered, the reader starts a procedure to automatically detect and recognize bar-
code types. The LEARN LED blinks to indicate the Learn mode is enabled.
The AutoLearn procedure is as follows:
1. Place one or more barcode types in the camera view. Hold the Xpress button until
LEARN LED lights.
2. Wait until the LEARN LED stays steady (indicating
the reader has detected the bar-
code.
3. To commit the learned barcode type(s) and exit, press the X-PRESS push button
twice.
4. AutoLearn will timeout 60 seconds after the last barcode type is decoded and no
learned barcode
type(s) will be committed.
If you do not want to accept the learned barcode, let it go and AV500/AV900 will time
out. The learned barcode will not be committed.
By default, the Test mode exits automatically 60 seconds after the last bar code is
decoded.
AutoLearn will only add new barcode type(s) to the configuration. The function will not
drop or modify existing barcode type(s) enabled in the configuration. AutoLearn will
only enable a learned barcode type if the barcode type does not already exist in the con-
figuration.
