46
AV500/AV900 2D CAMERA
CHAPTER 3
ELECTRICAL INSTALLATION
PREPARING FOR ELECTRICAL INSTALLATION
Before mounting any components, please do the following:
• Read all instructions before beginning your installation.
• Observe all electrical safety requirements discussed in the Introduction to this
manual.
• Define and confirm the accuracy of your application’s requirements.
• Review all installation-specific drawings.
• Review and plan the power requirements for your application.
• Review and plan the communications requirements for your application.
Electrical Installation must be performed by Qualified Service Technicians Only! Proce-
dures may involve exposure to high-voltage. A trained and authorized technician must
perform these procedures. Do not attempt to perform any electrical installation proce-
dures unless you are a trained technician.
The AV500/AV900 contain electronics that may be affected by electrostati
c discharge
(ESD). To prevent personal injury or damage to the unit, please follow the safety precau-
tions and warnings found in the References section at the beginning of this manual. Fail-
ure to follow these precautions may void your warranty.
The content of this manual may be superseded by any customer-specific documentation
provided by Datalogic. Before proceeding with any installation procedures, be sure to
review ALL documentation, especially content that contains details specific to your instal-
lation.
Everything should be MECHANICALLY INSTALLED before performing any ELECTRICAL
INSTALLATION. See Chapter 2 for mechanical installation details.
Most AV500/AV900 applications are shipped with the CBX connection box and all the nec-
essary cabling required to electrically install the system. If your system requires custom-
length cables or other special wiring, documentation specific to these requirements has
been provided in your shipment. This special documentation supersedes any contradictory
content in this manual.
To reduce the possibility of damage to the unit, check all cabling between the AV500/
AV900 camera and other devices for accuracy.
