Datalogic AV500 User Manual

MAINTENANCE TASKS
PRODUCT REFERENCE GUIDE 305
7. Apply the cleaning solution to a lint-free cloth.
8. Apply the cloth with the cleaning solution to the mirror.
9. Remove any streaks or remaining moisture from the mirror with a dry, soft, lint-
free cloth or lens pape
r.
10. Verify camera operation.
Cleaning the Photoelectric Sensor
If your application uses the photoelectric sensor option as a hardware trigger, be sure to
clean the photoelectric sensor periodically as outlined below.
1. Switch off the conveyor.
2. Switch off the camera system.
3. Clean the photoelectric sensor’s lens using the denatured alcohol solution and a
cot
ton swab or lens paper.
4. Clean the reflector using the denatured alcohol solution and a cotton swab or lens
paper.
5. V
erify photoelectric sensor operation.
Cleaning the Tachometer
If your application uses the tachometer option for tracking purposes, be sure to clean
the tachometer wheels periodically as outlined below.
1. Turn off the product transport.
2. Turn off the barcode reader by disconnecting the power source.
3. Using a clean, soft cloth, wipe the wheels
of the tachometer clean using a mild
detergent solution.
4. Before restarting the system, be sure the tachometer is making good contact with
th
e product tr
ansport.
5. Verify tachometer operation.
