INTRODUCTION
22
AV500/AV900 2D CAMERA
0LCC-75xx Kit with DS2 Light Array
The DS2 Light Array (Light Curtain), part of the LCC-75xx kit, is used to detect the pres-
ence of products in top mount applications as they en
ter the scanning area as well as
report the focusing data to the top mounted AV500/AV900. The AREAscanâ„¢ family of
the DS2 series covers controlled heights ranging from 150 to 2500mm, with 5m operat-
ing distances for high resolution versions, or 10m for low resolution versions.
Light Curtain Focusing
LCC-7501 AV7 LIGHT CURTAIN 150MM+CAB 10M 93ACC0170
LCC-7506 AV7 LIGHT CURTAIN 600MM+CAB 10M 93ACC0171
LCC-7509 AV7 LIGHT CURTAIN 900MM+CAB 10M 93ACC0172
LCC-7512 AV7 LIGHT CURTAIN 1200MM+CAB 10M 93ACC0173
