● Dirty or covered sensors may restrict the
detection. Do not cover the detection area
of sensors. Carefully clean the sensors if
necessary. The windshield in the front
area of interior rearview mirror should be
kept clean.
● In case of lost lane markings (blocked/lost
lane markings or large areas of road
surface covered by signs such as speed
bumps, etc.) during lane changes, the
lateral control may be degraded, so the
driver needs to maintain control of the
vehicle at all times during lane changes.
● In case of influence by the environment
(such as heavy rain/backlighting/road
reflection), the camera may not accurately
identify the lane marking type, which may
cause improper change lanes, so the
driver needs to drive carefully.
● According to the actual situation of lane
markings, the double dotted lines may
allow lane changes. It is recommended
not to request lane changes in the
direction of double dotted lines in road
sections where double dotted lines and
double solid lines are interspersed.
● After the TLC is enabled, all ICA related
functions will be enabled automatically,
the lane centering control function will not
be inhibited by the turn signal lamp, and
the system will correct the deviation
during automatic lane changes, so the
driver needs to drive carefully.
Use of function
The TLC can be enabled and used by the
following operations:
1. Select TLC through “CarCenter” – “Driving
assistance” – “ICA” on the MP5 display.
2. Press the left button on the steering
wheel to enable the TLC, so the ICA indicator
lamp (gray) on the instrument cluster will
go on, the TLC status indicator lamp (gray)
will go on, and gray lane markings will be
displayed at the center or on right side of the
instrument cluster.
3. After the TLC is activated, when the lane
change conditions are preliminarily met, the TLC
status indicator lamp (green) goes on.
4. When the turn signal lamp is turned on, the
vehicle will wait for about 1s before changing
lanes. If lane change failure is caused by lane
markings or a risk of collision in the target lane
when the turn signal lamp is just turned on, the
system will wait for a certain period of time,
during which if the lane change conditions are
met, the vehicle will continue to change lanes.
If there is a dangerous situation (unclear lane
markings or deceleration of a vehicle
approaching behind/vehicle ahead, etc.) during
lane changes, the vehicle will choose to return to
the original lane or complete the lane change
according to the position of the current lane.
Function status description
If TLC is selected through MP5 and ICA is
activated, when the system has no fault and the
lane markings on both sides are clear, the ICA
indicator lamp (green) on the instrument
cluster will go on, and the TLC status indicator
lamp (gray) will go on (if the lane change
conditions are not met preliminarily) or the TLC
status indicator lamp (green) will go on (if
the lane change conditions are met preliminarily)
and the lane markings will be highlighted in blue.
When the activation conditions are met and the
TLC is enabled without inhibiting conditions, if
the vehicle changes lanes normally after the turn
signal lamp is turned on, the instrument cluster
will display a blue arrow indicating that the lane
change is in progress.
When the activation conditions are met and the
TLC is enabled without inhibiting conditions, if
the lane change conditions are not met after the
turn signal lamp is turned on, the system will
display a red arrow and give a text prompt and
an audible alarm.
