5. Set the ENGINE START/STOP button to OFF
position;
6. Open the engine hood, and remove the
positive battery terminal trim cover;
7. Connect the red positive jumper cable by
connecting the positive terminal of the
inoperative battery to that of the other battery (①
→ ②). Connect it carefully so as to avoid short
circuit;
8. Connect the black negative jumper cable by
connecting the negative terminal to the ground
point (③ → ④). Connect it carefully so as to
avoid short circuit;
9. Start the engine of rescue vehicle to run it
for several minutes;
10. Depress the accelerator pedal of rescue
vehicle to keep the engine running at about
2,000r/min;
11. Start the engine of faulty vehicle as usual;
12. When the faulty vehicle's engine starts,
disconnect the jumper cables in the order
reverse to connecting so as to avoid short circuit.
○
A
: battery of faulty vehicle
○
B
: battery of rescue vehicle
○
C
: grounding point on faulty vehicle
1. If the battery of rescue vehicle is far away
from the battery of faulty vehicle, park two
vehicles in such a way that their batteries come
closer to each other;
2. Apply the parking brake;
3. Move the shift lever to “P” (parking) position.
4. Switch off all electrical consumers (such as
the lamps, heater and A/C);
