DongFeng Huge - Body Fuse Instructions

Replacing fuse
- 220 -
Emergencies
3
Body fuse instructions
No.
Capacity
Fuse function
Type
F1
5A
T-Box, IVI, IC IG1
power supply
MINI
F2
10A
BCM, BDC, ADAS,
reverse camera, FAPA,
BSD, IG1 signal
MINI
F3
15A
Washer motor IGN
MINI
F4
10A
Airbag IG1 power
supply
MINI
F5
5A
Front door window
regulator switch
backlight, rearview
mirror adjusting switch
backlight, central lock
backlight, rear door
window regulator
switch backlight
MINI
F6
5A
EPB switch indicator
lamp, shift switch
MINI
F7
10A
Multi-function touch
switch, A/C harness
interface, headlamp
leveling switch, seat
ventilation
MINI
F8
15A
EJB IG1 power supply
-
F9
10A
BMS, DCDC IG1 power
supply
-
F10
-
Reserved
-
F11
-
Reserved
-
F12
5A
SAS
MINI
F13
5A
Gateway IG1 power
supply
MINI
F14
15A
12V power outlet ACC
power supply
MINI
F15
10A
USB charger
MINI
F16
5A
BMS, EMS, BCM/BDC,
ACC feedback
MINI
F17
5A
Wireless charging,
ETC, sunroof, MP5,
rearview mirror switch,
branded A/V, IVI,
FAPA, ACC power
supply
MINI
F18
5A
ICB+ power
supply/wireless
charging
MINI
F19
15A
Branded A/V*
MINI
F20
20A
MP5 B+/MP5 and
control unit B+
MINI
F21
10A
OBD B+ power supply
MINI
F22
10A
T-Box 4G, FAPA,
ADAS, corner radar B+
power supply
MINI
F23
-
Reserved
-
F24
-
Reserved
-
F25
5A
A/C power supply 2
(with rearview mirror
folded)
-
F26
30A
Terminal block fuse
MINI
F27
25A
PDI electric running
board
MINI
F28
10A
Anti-pinch module, left
front door regulator
switch
MINI
F29
30A
Interior lamp power
supply
MINI
F30
10A
A/C control unit B+
MINI
F31
5A
Central locking system
switch, left front door
antenna B+, interior
mood lamp
MINI
F32
5A
Gateway
MINI
F33
10A
ENGINE START/STOP
button/rear defroster
relay power supply,
multifunction switch B+
power supply
MINI
F34
10A
ADAS camera, ACC
radar, RLS B+, ETC
MINI
F35
5A
DCDC B+ power
supply, OMS control
unit
MINI
F36
30A
Sunroof motor B+
MINI
F37
20A
Exterior lamp power
supply 1
MINI
F38
10A
BMS B+ power supply
MINI
F39
10A
BMS B+ power supply,
fuel tank leakage
diagnosis module,
FAPA backup B+
