Main parameters of vehicle
- 286 -
6
Technical parameters
Model series
Haoji
Vehicle model
DFM6470M5D1
DFM6470M5D2
DFM6470M5F1HEV
Front overhang (mm)
957
Rear overhang (mm)
938
Minimum ground clearance (mm)
(full load)
166
Approach angle/departure angle
(°)
17/25
Max. gradeability under full load
(%)
≥ 30
Main
tire
Tire specification
235/55 R18 or 235/50 R19
Pressure under light
load (2 people) (kPa)
Front: 230/rear: 230.
Heavy-load pressure
(full load) (kPa)
Front: 240/rear: 240.
Rim spec. and material
18×7.5J (aluminum alloy)/19×7.5J (aluminum alloy)
Spare
wheel
Rim spec. and material
18×4T (steel)
18×4T (steel)
-
Tire specification
T155/85 R18
T155/85 R18
-
Tire pressure (kPa)
420
420
-
Note: ● The fuel consumption data is measured according to GB/T 19233-2008 Measurement
Methods of Fuel Consumption for Light-duty Vehicles. Actual fuel consumption will vary depending on
driving habits, road conditions, climatic conditions, fuel quality, load, driving conditions, etc. during
actual driving.
Requirements for wheel dynamic balance
Wheel type
Aluminum
wheel
Steel wheel
Wheel
imbalance
(Main tire)
Inner rim ≤ 15g
Outer rim ≤ 25g
Reasonable use range of brake friction pair
Item
Standard size
Wear limit
Front brake pad
thickness
11.5mm
2mm
Front brake
disc thickness
30mm
28mm
Rear brake pad
thickness
11mm
2mm
Rear brake disc
thickness
12mm
10mm
Technical parameters of brake pedal
Brake pedal force
≤ 500N
Free travel
(8~23) mm
Distance from brake
pedal initial position to
carpet (vertical height)
112mm
Note: ● All technical data listed herein are for
reference and in no case should be used as the
basis for vehicle acceptance and registration,
which should be subject to national
announcement.
● The fuel (gas) hose is free of replacement.
It should be inspected during daily use or
maintenance. If it is damaged, it must be
replaced.
