7-3 Calibration Procedures
7-3-5 Resetting a Calibration
In case a wrong configuration was detected
after calibration was performed (e.g. wrong gas
connected) there is an option to restore the last
user saved calibration data:
Within the screen where to start the calibration
(either for span or zero) enter line 4:
A new screen appears with the option RESET
CALIBRATION.. Pressing the ENTER key in
this line results in a prompt for confirmation.
Choosing YES replaces the current calibration
data with the last calibration data (from
UserData;
5-4-3-8 "SAVE-LOAD", page
5-45).
CANCEL calibration!
START calibration!
ZeroGas 0.000 ppm
CO2.1 0.200 ppm
RESET calibration..
CO2.1 0.200 ppm
RESET calibration
Are you sure?
No!
Yes!
7-3-6 Verifying a Calibration
Starting from the measurement screen press
the DOWN key to open the MAIN MENU, enter
the CONTROL.. menu.
Enter the last line (APPLY GAS..)
For instruments without internal and/or
external valves simply apply either span or zero
calibration gas to the sample gas inlet. If the
calibration still is proper, the reading on the
measurement screen should show the related
value.
For instruments with internal and/or external
valves follow the procedure below:
Zero calibration..
Span calibration..
Apply gas..
Dual channel instrument:
Optional gas component selection menu -
Select the component to be setup
Control..
To Next Page
