X-STREAM
5-17
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5 User Interface
5-4 Menu System - Control Menu
5-4-2-4 Calibration Status Screen
The 1
st
line shows the currently applied gas
This line gives the measured concentration
Gasflow Sample
CO.1 13.304 ppm
Procedure None
Time 0 s
Information about which procedure is active
(none, purging, zero 1, zero 2, span 1,
span 2)
Remaining time till end of active procedure
The calibration status screen is selectable from
both ZERO CALIBRATION menu (
page 5-14)
and SPAN CALIBRATION menu ( page 5-15).
