X-STREAM
5-52
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5-4 Menu System - Status Menu
5-4-4-5 Calibration Status Screen
Status..
Calibration..
If a calibration is ongoing, this screens gives
some information about the status. But,
differing from the "Control.. - Zero/Span
Calibration.." screen, where the operator has
to select the channel (dual channel instruments
only), the data shown here are channel
independent, means they give a general
calibration status.
Gasflow Sample
Procedure None
Time 0 s
Gasflow:
Possible values are Sample, V1, V2 and V4.
These values represent the external or internal
valves used for autocalibration. Except for the
sample valve they are all operator configurable:
The operator can allocate each valve to zero
and span gas. Therefore this line shows the
activated valve (for V1, V2 and V4) only (and
not the related gas).
Procedure:
This line shows the current calibration status :
None: no calibration ongoing
Zero 1: channel 1 is zero calibrating
Span 1: channel 1 is span calibrating
Zero 2: channel 2 is zero calibrating
Span 2: channel 2 is span calibrating
Purging: the instrument is purging the gas path
The last line shows the remaining time for the
given procedure.
Note!
For a detailed description of calibration status
and how to perform calibrations chapter 7
Maintenance.
