X-STREAM
5-43
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5 User Interface
5-4 Menu System - Alarms Setup Menu
5-4-3-7 Alarms Setup Menu
If system is setup accordingly access level 3
code must be entered to access this menu.
Level1: 100 ppm
Function: Low
Level2: 500 ppm
Function: High
Enter a first concentration (threshold) level to
activate an alarm.
Select the alarm output operation mode for
level 1.
Available options:
Off, Low, High, Off FS, Low FS, High FS
( next page for a detailed description of
these options and on alarm settings)
Enter a second concentration (threshold) level
to activate an alarm.
Note!
The units for the level values are taken from
the related entry in the display setup menu.
Dual channel instrument:
Pressing the  key while any line is selected
returns to the optional gas component selec-
tion menu to open the same menu for the
other measuring channel.
Dual channel instrument:
Optional gas component selection menu -
Select the component to be setup
Select the alarm output operation mode for
level 2.
Available options:
Off, Low, High, Off FS, Low FS, High FS
( Chapter 6 for a detailed description of
these options and of alarm settings)
Setup..
Alarms..
