X-STREAM
Emerson Process Management GmbH & Co. OHG 7-7
Instruction Manual
HASAxE-IM-HS
05/2006
7 Maintenance
7-3 Calibration Procedures
7-3-2 Manual Calibration
Starting from the measurement screen press
the DOWN key to open the MAIN MENU, enter
the CONTROL.. menu.
Zero calibration..
Span calibration..

To start a calibration select one of the two upper
lines to perform the related calibration, e.g.
ZERO CALIBRATION:
Dual channel instrument:
Optional gas component selection menu -
Select the component to be calibrated.
7-3-2-1 Manual Zero Calibration
Before selecting any further line
make sure the required calibra-
tion gas is applied and flowing!
Supply all calibration gases with
the same flow as the sample gas
(recommeded approx. 1 l/min),
pressureless and utilizing the
right gas fitting (see sect. 3-4).
Ensure the warm-up time after
switching on has elapsed!
Warm-up time is 15 to 50 minutes
depending on installed measu-
ring system and configuration!
CANCEL calibration!
START calibration!
ZeroGas 0.000 ppm
CO2.1 0.200 ppm
The first line gives you the choice to cancel the
procedure now.
Select the second line to start the calibration.
Line 3 shows the calibration gas setup (here:
required zero gas concentration is 0.000 ppm),
while line 4 shows the currently measured gas
concentration.
Control..
