7 Maintenance
Before starting any of these procedures an
external device (e.g. computer) has to be
connected to the analyzer via the serial
interface.
7-6-4 Save / Restore to an External Device
Protocol: MODB RTU
MODB mode: 32Bit
ID number: 2
Interface: RS485/2w
1
st
menu page
Modbus protocol is disabled when transfering
data over the serial interface.
The ID the instrument uses for network
identification.
Input range: 1 ... 254
Installed RS interface variation.
Available options:
RS232, RS485/2w(ire), RS485/4w(ire)
Note!
Changing this parameter causes trouble if
not supported by the hardware!
2
nd
menu page
Baud rate: 19200
Parity: None
Serial interface baud rate.
Available options:
2400, 4800, 9600, 19200
Supported parity bit.
Available options:
None, Even, Odd
If system is setup accordingly access level 3
code must be entered to access this menu.
Make sure both devices (computer and
analyzer) provide the same type of interface:
RS 232, RS 485/2wire or RS 485/4wire. If need
be use a converter.
For the analyzer's interface open the SETUP -
COMMUNICATION screen:
Setup..
Communication..
