Instruction Manual
HASAxE-IM-HS
05/2006
X-STREAM
1-5Emerson Process Management GmbH & Co. OHG
1 Technical Description
Fig. 1-2: X-STREAM GP, terminals version, rear side view
1 23456
Fig. 1-3: X-STREAM GPS, plugs and sockets version, rear side view
1-2 X-STREAM GP, GPS
1 Gas inlet fittings
2 Optional gas inlet fittings
3 Cover for terminals (shown with
transparency)
4 Input / output signal terminals
5 Mains terminals
6 Mains fuses
1 23 45
1 Gas inlet fittings
2 Optional gas inlet fittings
3 Optional purge gas inlet
4 Mains appliance with fuses
5 Signals sockets
