Emerson Rosemount Xstream Series - Fig. 1-4: X-STREAM F, Front Side View & Rear Side View at Carrying Handle

Instruction Manual
HASAxE-IM-HS
05/2006
X-STREAM
1-7Emerson Process Management GmbH & Co. OHG
1 Technical Description
Fig. 1-4: X-STREAM F, front side view & rear side view at carrying handle
1-3 X-STREAM F
HEAVY INSTRUMENT!
X-STREAM F
gas analyzers, designed for wall mounting and/or outdoor
installation may weigh up to 25 kg (57 lbs), depending on installed options!
The upper part of the front door is designed to work as a carrying handle,
see fig. 1-4.
Use two persons or a suitable lifting device to move or carry the instrument!
