Emerson Rosemount Xstream Series - Fig. 1-7: X-STREAM F, Mains and Signal Terminals (Front Door Removed)

X-STREAM
Instruction Manual
HASAxE-IM-HS
05/2006
1-10 Emerson Process Management GmbH & Co. OHG
1-3 X-STREAM F
1 Terminals for signal cables
2 Mains EMI filter
3 Cable glands for mains and signal cables
4 Mains terminals with integrated fuses
Fig. 1-7: X-STREAM F, mains and signal terminals (front door removed)
1 423
