5 User Interface
5-4-3-5 Installed Options Setup Menu
If system is setup accordingly access level 3
code must be entered to access this menu.
2
nd
menu page
DigitalInp: Yes
PressSensor:Internal
Flow monitor: Yes
Select whether a flow monitor is installed (Yes)
or not (No).
Select whether digital inputs are installed (Yes)
or not (No)
Select if and in which way a barometric
pressure sensor is installed.
Available options:
Manual: No sensor available, ambient pres-
sure has to be entered manually for compen-
sation ( 5-4-3-3 Measurement Setup
Menu, page 5-26)
Internal: Internal digital pressure sensor
installed
External: Pressure input via network (e.g.
DeltaV)
Use CH2: If the digital sensor's accuracy is
not sufficient for specific applications, within a
single channel istrument an analog sensor may
be connected to the second measuring channel
electronics and used for compensation
purpose.
5-4 Menu System - Installed Options Setup Menu
Setup..
Installed options..
1
st
menu page
Select if and in which way valves are installed.
Available options:
Internal, External, Int(ernal)+Ext(ernal), None
Select whether a serial interface is installed
(Yes) or not (No)
Select whether an internal pump is installed
(Yes) or not (No).
Installed options
Valves: Internal
COM-Interf: Yes
Pump: Yes
