Emerson Rosemount Xstream Series User Manual

X-STREAM
5-53
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5 User Interface
5-4-4-6 Measurement Status Screen
Shows the detectors raw signal value. This is
the signal without being linearized,
compensated or converted to the expected
unit.
Dual channel instrument:
Pressing the  key returns to the optional gas
component selection menu to open the same
menu for the other measuring channel.
Temp-1 54 °C
Temp-2 44 °C
Pressure 1014 hPa

Dual channel instrument:
Optional gas component selection menu -
Select the component of interest.
1
st
menu page
Rawsignal 1962.1
ScrCurrent 704 mA
2
nd
menu page
Shows the current temperature measured by
sensor Temp-1.
Shows the current temperature measured by
sensor Temp-2.
Shows the current pressure value, either
measured by internal / external sensor or
manually entered.
5-4-3-5, page 5-41 for information about
how pressure is measured.
Shows IR source current.
5-4 Menu System - Status Menu
Status..
Measurement..
