7-3 Calibration Procedures
7-3-1 Preparing a Calibration
Before starting calibrations it is required to tell
the instrument the calibration gas concen-
trations.
Starting from the measurement screen press
the DOWN key to open the MAIN MENU, enter
the SETUP-CALIBRATION.. menu and directly
enter the CALIBRATION GASES.. menu.
Dual channel instrument:
Optional gas component selection menu -
Select the component to be setup
Calibration gases
ZeroGas: 0.0 ppm
SpanGas: 500.0 ppm
Enter the concentration value for the zero gas
to be used during zero calibration.
Dual channel instrument:
Pressing the  key while any line is selected
returns to the optional gas component selec-
tion menu to open the same menu for the
other measuring channel.
Enter the concentration value for the span gas
to be used during span calibration.
Note!
The units for the calibration gases are taken
from the related entry in the display setup
menu.
When done, press the LEFT key to return to
the CALIBRATION menu.
Setup..
Calibration..
Calibration gases..
