2-2-1-2 Sockets Version
Power Connection
Connection via IEC power appliance, provided
at the analyzer's rear panel (fig. 2-3).
Power fuses
Two fuses are located in the power appliance.
Fuse ratings: AC 230 V, 3.15 A, 5x20 mm
Fig. 2-3: X-STREAM GPS, (sockets version) -
power and signals connectors
1 Power appliance with EMI filter
2 Signal sockets/plugs
3 Fuse holder
3
1
2
