X-STREAM
2-9
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
2 Technical Data
Signal inputs / outputs
All signal lines need to be connected to 9 pole
and 25 pole submin-D-plugs and sockets,
located at the analyzer‘s rear panel (fig. 2-3).
Available signals: standard: Analog signal outputs
Relay status signals
Modbus interface (RS232; RS 485)
optional: Digital inputs/outputs
Detailed pin assignment
4-4 Installation, page 4-6.
2-2-1 X-STREAM GP, X-STREAM GPS
