1 Technical Description
1-3 X-STREAM F
Fig. 1-6: X-STREAM F, bottom view
1 Cable glands for mains and signal cables
2 Gas inlet and outlet fittings and purge gas outlet fitting
3 Purge gas inlet fitting
4 4 supports for wall mounting
