5-4 Menu System - Status Menu
5-4-4-1 Failure Status Screen
Status..
1 Failures..
The number starting the "Failures.." line in the
previous menu shows how much failures
currently are active (here: 1). So in the following
screens there will be only a related number of
entries showing Yes.
For a detailed description of failure messages
Chapter 8 "Troubleshooting".
Note!
If at least 1 failure shows up, the leftmost front
panel LED is illuminated (permanent red) and
relay 1 is activated.
ADC-Error No
Dual channel instrument:
Optional gas component selection menu -
Select the component of interest.
Dual channel instrument:
Pressing the  key returns to the optional gas
component selection menu to open the same
menu for the other measuring channel.
RAMmemory Yes
ROMmemory No

