X-STREAM
Instruction Manual
HASAxE-IM-HS
05/2006
1-14 Emerson Process Management GmbH & Co. OHG
Fig. 1-10: Single channel or serial tubing, with options
V1
V2
Sample gas
(V3)
V4
Analyzer
Solenoid
valves
(option)
Sample pump (option)
Gas outlet
(OUT K1)
1-5 Gaspath Design
