5 User Interface
5-4 Menu System - Analog Output Setup Menu
Table 5-2: Analog Output Signal Setting & Operation Modes
Signal
Range
Setting
Operation Mode
Failure Signal
Level acc. NE 43
Valid Measuring
Signal Range
Measuring Signal
Exceeds Lower
Range Limit
Measuring Signal
Exceeds Upper
Range Limit
Measuring
System
Failure
Cable
Break
Channel 2
when not
equipped
0-20mA
Dead-Zero - 0 … 20 mA < -19 mA > 21 mA undefined 0 mA 0 mA
4-20mA
Life-Zero - 4 … 20 mA < -19 mA > 21 mA undefined 0 mA 4 mA
LL0-20mA
similiar
Dead-Zero
below 0 … 20 mA -0,2 mA 20,5 mA -2 mA 0 mA -0.2 mA
LL4-20mA
similiar
Life-Zero
below 4 … 20 mA 3,8 mA 20,5 mA 2 mA 0 mA 3.8 mA
HL0-20mA
similiar
Dead-Zero
above 0 … 20 mA -0,2 mA 20,5 mA >21 mA 0 mA -0.2 mA
HL4-20mA
similiar
Life-Zero
above 4 … 20 mA 3,8 mA 20,5 mA >21 mA 0 mA 3.8 mA
Output Signal, when…
