X-STREAM
3-10
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
3-2 Oxygen Measurement
Fig. 3-6: Paramagnetic Oxygen Detector,
Assembly Principle
1 Permanentmagnet
2 Platinum wire
3 Mirror
4 Glass ball
5 Loop
6 Photodetector
7 Light source
8 Preamplifier
9 Display
10 Gas inlet
11 Gas outlet
415 368
11 7 9
2
10
Table 3-2: Medium affected Materials within
Paramagnetic Oxygen Sensor
