7-6-4-2 Restore COMPort to CfgData
7-6 Save / Restore Configuration Data Sets
If system is setup accordingly access level 3
code must be entered to access this menu.
Starting from the measurement screen press
the DOWN key to open the MAIN MENU, enter
the SETUP and next the SAVE-LOAD.. menu.
COMPort>CfgData
Are you sure?
No!
Yes!
A screen appears to confirm the operation:
Select Yes! and after pressing the ENTER key
a new screen shows up showing the current
status.
Save-Load
CfgData>COMport!
COMport>CfgData..
Verify!
Now select the "COMPort>CfgData.." line and
press the ENTER key.
Copying data
- PLEASE WAIT -
Procedure X:078000
The instrument now overwrites the currently used
(and possibly changed by operator) analyzer
setup by the data stored in an external device.
The restored data is then called CfgData and
used for operating the analyzer.
When the procedure has finished, the
COMMAND EXECUTED screen shows up.
(i)
-COMMAND EXECUTED-
Before starting this procedure connect an
external device (e.g. computer) via the serial
interface to the analyzer.
Open a standard terminal software on the
computer with it's serial interface setup the
same way as the analyzer's.
Note!
The analyzer's Modbus protocol will be
disabled during COMPort data transfer.
