Emerson Rosemount Xstream Series - Alarms Status Screen

X-STREAM
5-54
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5-4-4-7 Alarms Status Screen
Dual channel instrument:
Pressing the  key returns to the optional gas
component selection menu to open the same
menu for the other measuring channel.
Dual channel instrument:
Optional gas component selection menu -
Select the component of interest.
Shows the current concentration alarm status
for the selected channel. If a concentration
alarm is active the related status shows On,
otherwise it is Off.
An active concentration alarm gives a corres-
ponding message in the measuring screen, too
(e.g. CO.1 Alarm Level1).
5-4 Menu System - Status Menu
Status..
Alarms..
Alarms
Level1 Off
Level2 Off
