5-4-2-1 Zero Calibration Menu
5-4 Menu System - Control Menu
Dual channel instrument:
Pressing the  key returns to the optional gas
component selection menu to perform the
same action for the other measuring channel.
2
nd
menu page
RESET calibration..
Status..
CO2.1 134.1 ppm
Enter this line and start the related procedure
to reset calibration parameters to the data
stored as user configuration. (By default this is
the factory data set, if not manually overwritten
by the user, 5-4-3-8 "SAVE-LOAD-UP-
DATE" menu on page 5-45).
Current gas concentration
Note!
For detailed descriptions of how to perform
calibrations chapter 7 Maintenance.
When this line is selected, pressing the  key
cancels the zero calibration procedure without
any changes
When this line is selected, pressing the  key
starts the zero calibration procedure
Current zero gas concentration setting (Infor-
mation only; setup zero gas concentration in
the "SETUP" menu
5-4-3-2-1, page 5-24)
Current gas concentration
1
st
menu page
CANCEL calibration!
START calibration!
ZeroGas 0.0 ppm
CO2.1 134.1 ppm
Select this line and press the  key to view
the calibration status screen ( page 5-17)
Control..
Zero calibration..
Dual channel instrument:
Optional gas component selection menu -
Select the component to be calibrated.
To Next Page
