Emerson Rosemount Xstream Series - Control Menu

X-STREAM
5-13
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5 User Interface
5-4 Menu System - Control Menu
5-4-2 Control Menu
Control..
Lock menus!
Acknowledgements..
Pump: Off
Zero calibration submenu
5-4-2-1, page 5-14
Span calibration submenu
5-4-2-2, page 5-15
Toggle internal pump status: On / Off
(only with optional internal pump)
Requires parameter "PumpControl" set to
Menu ( 5-4-3-4, page 5-33)
Pressing the  key while this line is selected
immediately locks all menus whose code
parameter in the menu access setup is set
to On or 1 min ( 5-4-3-1-2, page 5-24)
Apply gas submenu
5-4-2-5, page 5-18
2
nd
menu page
If system is setup accordingly access level 1
code must be entered to access this menu.
1
st
menu page
Acknowledgements submenu
5-4-2-6, page 5-19
Zero calibration..
Span calibration..
Adv. calibration..
Apply gas..
Advanced calibration submenu
5-4-2-3, page 5-16
