X-STREAM
5-18
Instruction Manual
HASAxE-IM-HS
05/2006
Emerson Process Management GmbH & Co. OHG
5-4-2-5 Apply Gas Menu
Toggle between Sample, ZeroGas, SpanGas
and None using the  and  keys.
Entering the selected value using the  key
opens the related valve and closes all other
valves (except for None: all valves are closed).
Note!
This menu is available only if the parameter
"Valves" in the INSTALLED OPTIONS setup
menu is other than none
5-4 Menu System - Control Menu
Dual channel instrument:
Pressing the  key returns to the optional gas
component selection menu to perform the
same action for the other measuring channel.
Dual channel instrument:
Optional gas component selection menu -
Select the component to be modified.
Control..
Apply gas..
Apply gas: Sample
