Emerson Rosemount Xstream Series User Manual

Instruction Manual
HASAxE-IM-HS
05/2006
X-STREAM
1-13Emerson Process Management GmbH & Co. OHG
1 Technical Description
1-5 Gaspath Design
Depending on the application and the selected
options several gas paths configurations are
1-5-5 Gas Path Variations
available, as shown in the following figures
(examples):
Fig. 1-8: Single channel or serial tubing
Gas inlet
(IN K1)
Gas outlet
(OUT K1)
Analyzer
Fig. 1-9: Dual channel parallel tubing
Analyzer
Gas inlet
(IN K1)
Gas inlet
(IN K2)
Gas outlet
(OUT K1)
Gas outlet
(OUT K2)
