5 User Interface
5-4 Menu System - Status Menu
5-4-4 Status Menu
Status..
1 Failures..
0 Check requests..
1 Function checks..
0 Off spec..
Measurement status menu
5-4-4-6, page 5-53
Alarms status menu
5-4-4-7, page 5-54
Check requests status screen
5-4-4-2, page 5-49
1
st
menu page
Failures status screen
5-4-4-1, page 5-48

Calibration..
Measurement..
Alarms..
2
nd
menu page
Calibration status menu
5-4-4-5, page 5-52
Note!
All menu lines within this status menu and
it's submenus are read-only lines! They are
for information only.
Function checks status screen
5-4-4-3, page 5-50
Off spec status screen
5-4-4-4, page 5-51
The 1
st
page menu lines include a number in
the first row, showing the number of currently
set messages of the given type.
