X-STREAM
Emerson Process Management GmbH & Co. OHG7-32
Instruction Manual
HASAxE-IM-HS
05/2006
7-3 Calibration Procedures
CO2.1 0.000 ppm
Procedure Zero 1
Time 0 s
Gasflow Sample
CO2.1 0.000 ppm
Procedure Purging
Time 10 s
A confirmation popup appears, replaced by the
calibration procedure screen, whose content
depends on which calibration was cancelled
(manual or auto).
Refer to the figures to the left :
The upper screen comes up when a manual
calibration was cancelled.
The lower screen shows up when an autocali-
bration was cancelled: As the sample valve
was opened again, a postpurge procedure was
started.
Press the LEFT key to exit these screens.
