Preparation of power cable
The power power inlet appliance is of type IEC.
Use a standard power cable with IEC connector
complying with your local requirements to
supply the instrument with power.
Fig. 4-9: IEC power input plug
PE
4-4-1 Installation - X-STREAM GP, X-STREAM GPS
PE = Protective
Earth
