M4-60 031914
AR15 Gateway Module: The AR15 Gateway
Module transfers “Output” signals from the
Computer to the Combined I/O and the
Stepper Modules and sends operational
information over the Profibus Cable to the
Computer. There are 4 “Status” LED’s on the
AR15 Module. (Illustration 136) The LED’s
are “Status,” “Error,” “RxD” and “TxD.”
ILLUSTRATION 136
AR15 AR16
