STEP 8 HONE THE KNIFE
Engage the Hone Stone and the Deburr Fiber Pad.
1. Close the door. The system will not operate
with the door open.
2. Pull out the “MASTER OFF” button.
(Illustration 17)
3. Select the number of rotations on the
thumbwheel switch. The first digit must be
set to “A” and the last digit must be set to
c/o. A good starting point is to select 40
rotations, set the switch to A040c/o.
4. Turn the selector switch to “JOG” and hold
for one complete rotation of the Knife.
Check that the hone stone contacts the
Knife edge all the way around the cutting
radius. If they do not, adjust the stone as
described in STEPS 5-4.
5. Momentarily turn the selector switch to
“RUN.” The unit will remain running and stop
after the number of rotations selected on the
thumbwheel switch.
6. Open the door and check the cutting edge to
see if it is sharp. If the Knife is still dull,
engage the hone stone and deburr pad,
close the door and repeat STEPS 8-5
through 8-7.
THUMBWHEEL
SWITCHES
SELECTOR
SWITCH
MASTER OFF
BUTTON
ILLUSTRATION 17
MAIN POWER
SWITCH
JOG
RUN
