CR Console Operation Manual
2 - 6 2009. 09 897N0519H
2.2 Operation Screen
This section explains the operation screen for the basic operations ranging from reception to
completion of a study.
(About the various lists, refer to [
Chapter 5. OPERATIONS - LIST
].)
2.2.1 Receiving Studies
Shown below is the transition outline of the basic screens for receiving studies.
(1) Inputting Patient Information ([3.1.1 Inputting Patient Information])
“Patient Information Input Screen”
(2) Selecting Exposure Menu ([3.1.3 Selecting Exposure Menu])
“Exposure Menu Selection Screen”
To (2) Selecting Exposure Menu
To 2.2.2 Confirming Study Details
To Next Page
