CR Console Operation Manual
2 - 8 2009. 09 897N0519H
2.2.3 Issuing Examination Orders
Shown below is the transition outline of the basic screens for issuing examination orders.
(1) Issuing Examination Orders ([3.3 Issuing Examination Orders])
2.2.4 Executing Studies
Shown below is the transition outline of the basic screens for “Executing Studies”.
Two display modes are available on the Study Execution Screen : One-image display mode and six-
image display mode.
(1) Starting a Study ([3.4.1 Starting a Study])
“Study Execution Screen” (One-image display mode)
“Study Execution Screen” (Six-image display mode)
From 2.2.2 Confirming Study Details
Starting a study
“Exposure Menu Selection Screen”
Reserving a study
“Local WL list”
“Scroll View”
“Examination Order Issuance Screen”
To 2.2.4 Executing Studies
To Next Page
