EI/DI display field
: The EI and DI (defined in IEC 62494-1:2008) of the displayed image
are displayed.
The EI and DI can be displayed only for normal images (except
mammography images). They do not appear for energy subtraction
images, long-view images, etc. When an image is replaced with other
one, the values are updated accordingly.
The EI/DI display field can be repositioned by moving the
□
mark.
Whether the EI/DI display field is displayed or not depends on the
setting made at the time of installation.
NOTES
•
In case that a cassette-type Image Reader is used, the EI and DI
values are displayed properly only when the type of the IP is ST-
VN, ST-VI, or ST-BD.
•
When using the EI and DI values for image quality management,
calibrations of Image Readers should be carried out periodically.
•
The EI and DI may vary if a wrong exposure menu was selected.
*
: Saves edited image information.
*
: Terminates image information editing and returns to the previous
screen.
* The displayed button and its operation differ depending on the settings performed at installation.
For details, see [
4.6 Completing Image Edit
].
NOTE
• Displaying either
or / varies depending on the setting performed at
installation. When
/ is displayed, select and then to reflect the
setting.
Display property settings of QA buttons in a palette or QA image controller buttons can be set in
“User Utility”.
Refer to [
Chapter 10 CUSTOMIZING THE SCREEN DISPLAY / CR Console OPERATION
MANUAL - THE USER UTILITY OPERATIONS
].
