Note -
Connect the crossbar cables in their original positions by referring to the notes that
you made before the start of maintenance.
holder.
b. Remove the screw securing the cable holder, and then rotate the cable holder
by 180 degrees to install it on the supporting column at the rear of the rack.
c. Connect all the crossbar cables to the crossbar unit.
d. Use the hook-and-loop fastener to fix the crossbar cables in
place to the cable
support.
Procedure when equipment rack model 16xx is used
a. Remove the crossbar cables from the hook-and-loop fastener installed on the
supporting column at the rear of the rack.
b. Connect all the crossbar cables to the crossbar unit.
c. Use the hook-and-loop fastener to fix the crossbar
cables in place to the cable
support.
6.1.5 Installing the front cover
If the front cover of the SPARC M10-4/M10-4S was removed for maintenance to
install an FRU at the front of or inside the chassis, install the front cover after
installing the FRU.
1.
To install the front cover, insert the tabs of the front cover into the notches at
the bottom front
of the chassis.
Chapter 6 Restoring the System 91
