Fujitsu M10-4 - Removing a Fan Unit

(1)
(2)
(3)
(4)
(5)
Location number Component
1 Fan unit (FANU#0)
2 Fan unit (FANU#1)
3 Fan unit (FANU#2)
4 Fan unit (FANU#3)
5 Fan unit (FANU#4)
Caution -
Before you handle any components, wear a wrist strap to ground any static
electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be damaged. For details, see "1.5 Notes
Regarding Static Electricity."
Figure 11-1
Location of fan units
11.2 Removing a Fan Unit
This section describes the procedure for removing a fan unit. Enable the removal of
the fan unit before attempting to remove it. For details, follow the procedure in
"Chapter 7 Maintenance Flow."
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014260
