Fujitsu M10-4 - Removing a PCI Express Card

A
Figure 8-5
Removing the PCIe card cassette
8.3.2 Removing a PCI Express card
1.
Remove the cover by lifting it up while pushing the clip (A in the figure) of the
cover inwards.
Figure 8-6
Clip at rear of cover
2.
Remove the screw securing the PCIe card cassette.
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014174
