Table 3-3
Whether inactive maintenance (replacement/addition/removal) is enabled for each FRU (conti nued)
-: Maintenance cannot be performed.
FRU Building block configuration
Inactive/hot maintenance Inactive/cold maintenance
PCIe card OK OK
PSU backplane unit - OK
Operation panel - OK
Crossbar cable - OK
XSCF BB control cable -OK
XSCF DUAL control cable -OK
Table 3-4
Whether system-stopped maintenance (replacement/addition/removal) is enabled for each FRU
-: Maintenance cannot be performed.
FRU Single-chassis configuration Building block configuration
System-stopped/hot
maintenance
System-stopped/
cold maintenance
System-stopped/hot
maintenance
System-stopped/
cold maintenance
CPU memory unit - OK - OK
Memory - OK - OK
Crossbar unit (*1) - OK - OK
Power supply unit OK OK OK OK
Fan unit OK OK OK OK
Internal disk OK OK OK OK
PCIe card OK OK OK OK
PSU backplane unit - OK - OK
Operation panel - OK - OK
Crossbar cable (*2) - OK - OK
XSCF BB control cable (*2)---OK
XSCF DUAL control cable (*2)---OK
*1 The unit is mounted only in the SPARC M10-4S.
*2 The cable is mounted only in a building block configuration using the SPARC M10-4S.
3.4 System-stopped Maintenance
The type of maintenance performed with all physical partitions on the system
stopped is referred to as system-stopped maintenance.
Table 3-4 shows whether system-stopped maintenance is enabled for each FRU.
