Fujitsu M10-4 - Installing a Fan Unit

Note -
Place the removed fan unit on a grounded antistatic ESD mat.
Note -
Do not force the fan unit into the slot. Using excessive force may damage the
component or the chassis.
1.
Pull out the fan unit while raising its lever.
Figure 11-2
Lever of fan unit
2.
Carefully remove the fan unit from its slot.
11.3 Installing a Fan Unit
This section describes the procedure for installing a fan unit.
1.
Carefully insert the fan unit into its slot.
Chapter 11 Maintaining the Fan Units 261
