Table 2-17
LEDs on the internal disk and their states
Name Color Status Description
READY Green Blinking Indicates that the disk is being accessed. This
LED is normally on, but it blinks while the
disk is being accessed.
While the LED is blinking, maintenance work
such as the removal of the disk cannot be
performed.
Off Indicates that maintenance work such as the
removal of the disk can be performed.
CHECK Amber On Indicates that an error has occurred.
Blinking
(*1)
Indicates that the component requires
maintenance (This function is also referred to
as the "locator").
Off Indicates the normal state.
*1 The blink interval is 1 second (1 Hz).
2.5 Confirming the Types of Cable
This section describes the types of cables connected to the SPARC M10-4/M10-4S and
the locations of the ports.
The types and number of the cables to be used vary depending on the configuration.
2.5.1 Types of cable
In a building block configuration, the following cables are used for making a
connection between the SPARC M10-4S systems and between the SPARC M10-4S
and the crossbar box:
■
Crossbar cable
In a building block configuration, this is used to connect the SPARC M10-4S units
to each other or to connect the SPARC M10-4S to a crossbar box.
■
XSCF BB control cable
This is used to connect the XSCFs mounted in the SPARC M10-4S or crossbar box
chassis.
An XSCF mounted in a chassis becomes the master XSCF and monitors or controls
the entire system. XSCFs other than the master XSCF act as slaves and monitor or
control each chassis.
■
XSCF DUAL control cable
This is used to connect the master XSCF to a standby XSCF and duplicate XSCF.
One of the slave XSCFs functions as the standby XSCF. If an abnormality occurs
Chapter 2 Understanding the System Components 29
