Table 2-14
LED on the fan unit and its states (continued)
Name Color Status Description
Off Indicates the normal state.
*1 The blink interval is 1 second (1 Hz).
Table 2-15
LED on the power supply unit and its states
Name Color Status Description
CHECK
Green On Indicates that the input power is turned on
and power is being supplied normally.
Blinking
(*1)
Indicates that the input power is being
disconnected.
Amber On Indicates that an error has occurred.
Indicates that the input power to this power
supply unit is turned off in redundant
operation.
Blinking
(*1)
Indicates a warning (An error has occurred
but this power supply unit is operating).
Off Indicates that power is not being
supplied.
*1 The blink interval is 1 second (1 Hz).
Table 2-16
LEDs on the PCIe card slot and their states
Name Color Status Description
POWER Green On Indicates that power is being supplied.
Off Indicates that power is not being supplied.
ATTENTION Amber On Indicates that an error has occurred.
Blinking
(*1)
Indicates that the component requires
maintenance (This function is also referred to
as the "locator").
Off Indicates the normal state.
*1 The blink interval is 1 second (1 Hz).
